Collier – Online mercury monitor for natural gas

Continuous monitoring with automatic internal calibration

Zero Consumables

Maintenace Free

To request a quote, please submit the following form. You will be contacted by our team.

You may also contact us directly at jay@picoyune.com for additional inquiries

Collier Product Specifications

Principle	Direct nanoplasmonic sensing
Range	0.01–10,000 µg/m³
Sample frequency	Variable (4 to >100 per hour)
Calibration	Automatic, on-board permeation source
Flowrate	<1 L/min and <15 psig
Electrical	1 W, 5–24 VDC input
Data	On device storage and networked (wired/wireless)

Enclosure explosion proof certifications

ATEX	Flameproof protection; II 2GD; Ex db IIC Gb; Ex tb IIIC Db; IP66/IP68; Tamb: -55°C to +85°C
IECEx	Flameproof and dust protection; Ex db IIC Gb; Ex tb IIIC Db; IP66/IP68; Tamb: -55°C to +85°C
CSA	Class I, Division 1, Groups A, B, C, D; Class II, Division 1, Group E, F, G; Class III; Ex db IIC Gb; Ex tb IIIC Db; Class I, Zone 1, AEx db IIC Gb; Zone 21, AEx tb IIIC Db; IP66/IP68/TYPE 4X; Tamb: -55°C to +85°C
UL	Class I, Division 1, Groups A, B, C and D; Class II, Division 1, Groups E, F and G; Class III; Class I, Zone 1, AEx db IIC Gb; Zone 21, AEx tb IIIC Db; Ex tb IIIC Db; IP66/IP68/TYPE 4X; Tamb: -55°C to +85°C
CE	EU and IECEx Attestation of Conformity

Download PDF

Picoyune replaces complex equipment with reliable, portable, and easy to use devices.
